Toyota 4Runner Gen 4 (2003-2009) Wheel & Tire Fitment Guide — Offset, Lift, & Recommendations
Upgrading the wheels and tires on your Toyota 4Runner Gen 4 (2003-2009) is the single most effective way to improve off-road capability and street presence. However, choosing the wrong offset or tire size leads to rubbing against the frame, UCA, or fender flares. This guide breaks down the exact fitment specs, lift requirements, and recommended setups verified by owners.
How to choose wheels and tires for your Gen 4 Gen 4Runner
For the 2003-2009 models, the factory specifications dictate your starting point. Going larger requires balancing your wheel width, offset, and suspension lift height to prevent rubbing.
- Bolt Pattern: 6x139.7
- Center Bore: 106.1 mm
- Stock Wheel Size: 17"
- Stock Tire Size: 265/70R16 or 265/65R17
- Stock Offset: +25mm
Top Fitment Configurations
Here is how different tire sizes fit based on your suspension level and wheel offset. These setups stack cleanly on mobile and span horizontally on desktop for easy scanning:
Recommended Fitment Setups
Stock Setup
With a stock setup, the recommended wheel configuration is 17x8.5 +25 paired with 265/70R17. Factory 17" on sport trims; 265/70R17 is the sweet spot
Leveling Kit (2") Setup
With a leveling kit (2") setup, the recommended wheel configuration is 17x8.5 0 paired with 275/70R17. 275/70R17 on leveling kit is clean - no rubbing
3" Lift (Max Recommended) Setup
With a 3" lift (max recommended) setup, the recommended wheel configuration is 17x9 0 to -12 paired with 285/70R17 or 33x12.5R17. 3" is max recommended front lift; UCAs recommended. 33" tires fit well
Frequently Asked Fitment Questions
Click below to expand direct answers to the most common fitment queries for the Toyota 4Runner Gen 4:
What is the bolt pattern and center bore for the Gen 4 4Runner?
The Toyota 4Runner Gen 4 (2003-2009) utilizes a 6x139.7 bolt pattern and a 106.1mm center bore. Ensure your aftermarket wheels are hub-centric or use high-quality hub-centric rings.
Can I run 33-inch tires on stock suspension?
Yes, but it requires highly specific offset wheels (generally around stock offset) and minor trimming of the fender liner to clear full steering lock.
What is the factory offset and how does it affect rubbing?
The factory wheel offset is +25mm. Moving to a lower or negative offset wheel pushes the tire outward. While this creates a aggressive wide stance, it increases the scrub radius, which can cause tires to rub the rear of the fender liner and the body mount.
