Toyota 4Runner Gen 5 (2010-2024) Wheel & Tire Fitment Guide — Offset, Lift, & Recommendations
Upgrading the wheels and tires on your Toyota 4Runner Gen 5 (2010-2024) is the single most effective way to improve off-road capability and street presence. However, choosing the wrong offset or tire size leads to rubbing against the frame, UCA, or fender flares. This guide breaks down the exact fitment specs, lift requirements, and recommended setups verified by owners.
How to choose wheels and tires for your Gen 5 Gen 4Runner
For the 2010-2024 models, the factory specifications dictate your starting point. Going larger requires balancing your wheel width, offset, and suspension lift height to prevent rubbing.
- Bolt Pattern: 6x139.7
- Center Bore: 106.1 mm
- Stock Wheel Size: 17" or 18"
- Stock Tire Size: 265/70R17 or 265/65R17
- Stock Offset: +25mm
Top Fitment Configurations
Here is how different tire sizes fit based on your suspension level and wheel offset. These setups stack cleanly on mobile and span horizontally on desktop for easy scanning:
Recommended Fitment Setups
Stock Setup
With a stock setup, the recommended wheel configuration is 17x8.5 0 to +25 paired with 265/70R17. Most popular stock setup; TRD Off-Road runs 265/70R17 from factory
Stock Setup
With a stock setup, the recommended wheel configuration is 17x8.5 0 paired with 275/70R17. 275/70R17 on stock - push fender liner for clearance
Leveling Kit (2") Setup
With a leveling kit (2") setup, the recommended wheel configuration is 17x8.5 0 to -12 paired with 275/70R17. Most popular mild upgrade combo; 2" level + 275/70R17
Leveling Kit (2") Setup
With a leveling kit (2") setup, the recommended wheel configuration is 17x8.5 -10 to -12 paired with 285/70R17. 285s on 2" level possible with fender liner push; UCAs help
3" Lift Setup
With a 3" lift setup, the recommended wheel configuration is 17x8.5 0 to -12 paired with 285/70R17. 3" lift + 285/70R17 is most popular off-road build; clean with UCAs
4-6" Lift Setup
With a 4-6" lift setup, the recommended wheel configuration is 17x9 0 to -12 paired with 315/70R17 or 35x12.5R17. 315/70R17 on 4-6" lift with UCAs is the ultimate 4Runner build
Frequently Asked Fitment Questions
Click below to expand direct answers to the most common fitment queries for the Toyota 4Runner Gen 5:
What is the bolt pattern and center bore for the Gen 5 4Runner?
The Toyota 4Runner Gen 5 (2010-2024) utilizes a 6x139.7 bolt pattern and a 106.1mm center bore. Ensure your aftermarket wheels are hub-centric or use high-quality hub-centric rings.
Can I run 33-inch tires on stock suspension?
Yes, but it requires highly specific offset wheels (generally around stock offset) and minor trimming of the fender liner to clear full steering lock.
What is the factory offset and how does it affect rubbing?
The factory wheel offset is +25mm. Moving to a lower or negative offset wheel pushes the tire outward. While this creates a aggressive wide stance, it increases the scrub radius, which can cause tires to rub the rear of the fender liner and the body mount.
