Toyota Land Cruiser 100 Series (1998-2007) Wheel & Tire Fitment Guide — Offset, Lift, & Recommendations
Upgrading the wheels and tires on your Toyota Land Cruiser 100 Series (1998-2007) is the single most effective way to improve off-road capability and street presence. However, choosing the wrong offset or tire size leads to rubbing against the frame, UCA, or fender flares. This guide breaks down the exact fitment specs, lift requirements, and recommended setups verified by owners.
How to choose wheels and tires for your 100 Series Gen Land Cruiser
For the 1998-2007 models, the factory specifications dictate your starting point. Going larger requires balancing your wheel width, offset, and suspension lift height to prevent rubbing.
- Bolt Pattern: 5x150
- Center Bore: 110 mm
- Stock Wheel Size: 17"
- Stock Tire Size: 275/65R17 or 285/65R17
- Stock Offset: +60mm
Top Fitment Configurations
Here is how different tire sizes fit based on your suspension level and wheel offset. These setups stack cleanly on mobile and span horizontally on desktop for easy scanning:
Recommended Fitment Setups
Stock Setup
With a stock setup, the recommended wheel configuration is 17x7.5 +60 paired with 275/65R17. IMPORTANT: 100 Series uses 5x150 bolt pattern. Stock offset is +60mm (very tucked). Aftermarket sweet spot is +20-+25mm offset
Stock (Aftermarket Wheels) Setup
With a stock (aftermarket wheels) setup, the recommended wheel configuration is 17x9 +20 to +25 paired with 285/75R16 or 285/65R18. Simply swapping to aftermarket wheels at +20-+25 offset + 285/65R18 works without lift; popular overlanding build
Mild Lift (2" OME) Setup
With a mild lift (2" ome) setup, the recommended wheel configuration is 16x8 +10 to +20 paired with 285/75R16. OME 2" lift with 285/75R16 on 16x8 is the classic 100 series build; excellent fitment
3" Lift Setup
With a 3" lift setup, the recommended wheel configuration is 17x8 +20 paired with 285/70R17 or 295/70R17. 3" lift + 285/70R17 is very popular; going to 295/70R17 needs fender liner push
Frequently Asked Fitment Questions
Click below to expand direct answers to the most common fitment queries for the Toyota Land Cruiser 100 Series:
What is the bolt pattern and center bore for the 100 Series Land Cruiser?
The Toyota Land Cruiser 100 Series (1998-2007) utilizes a 5x150 bolt pattern and a 110mm center bore. Ensure your aftermarket wheels are hub-centric or use high-quality hub-centric rings.
Can I run 33-inch tires on stock suspension?
No, running 33-inch tires on a stock suspension setup is not recommended. It will cause rubbing on the fender liners and body mounts during articulation and full lock steering. We recommend at least a 2-3 inch lift or leveling kit.
What is the factory offset and how does it affect rubbing?
The factory wheel offset is +60mm. Moving to a lower or negative offset wheel pushes the tire outward. While this creates a aggressive wide stance, it increases the scrub radius, which can cause tires to rub the rear of the fender liner and the body mount.
